PUNCTURE, EMERGENCY SPARE WHEEL (3/4)
To refit a wheel
To carry out this operation, the cable
must be unwound.
If the cable has been wound back up on
its own, unwind it again as follows:
– Pull the handle to unwind the cable,
– press the button located under
handle 5 to hold the unwound cable,
then guide it down;
– recover the cable from underneath
the vehicle;
– attach the cable end piece to the
wheel support.
You may refit the wheel.
After changing a wheel, position the
replaced wheel on support 9, with the
valve facing the ground. Depending
on the vehicle, reposition shim 8. Clip
cable 6 into housing 7, then push the
wheel underneath the luggage com-
partment (tab 10 towards the rear of
the vehicle).
Position yourself behind the vehicle and
pull handle 5 to raise the wheel until it is
anchored under the vehicle.
Make sure that no one has
their fingers close to the
cable when you move the
handle. Risk of injury.
5
6
7
8
9
10
