Renesas Starter Kit+ for RZ/T2M 6. Configuration
R20UT4939EG0100 Rev. 1.00 Page 46 of 87
Apr 20, 2022
Table 6-24: External BUS & SDRAM Configuration Option Links (3)
Signal name
MPU
MPU Peripheral Selection
Destination Selection
Pin
Port
Signal Fit DNF
Interface
/Function
Fit DNF
BSC_D09_TRACE_CLK F9 P22_2
BSC_D09
IC28.16
(SW6-1 = ON)
-
IC22.F3
-
-
IC23.44
-
-
JA3-A.30
-
-
TRACE_CLK
IC28.17
(SW6-1 = OFF)
- CN9.6 - -
BSC_D08_TRACE_CTL C7 P22_1
BSC_D08
IC28.42
(SW6-1 = ON)
-
IC22.H2
-
-
IC23.42
-
-
JA3-A.29
-
-
M2_POE
IC28.41
(SW6-1 = OFF)
SW6-4 = ON
SW6-3 = OFF JA5-A.16 - -
TRACE_CTL
IC28.41
(SW6-1 = OFF)
SW6-3 = ON
SW6-4 = OFF CN9.36 - -
BSC_D07_TRACE_D7 B6 P22_0
BSC_D07
IC28.11
(SW6-1 = ON)
-
IC22.G7
-
-
IC23.13
-
-
JA3-A.24
-
-
TRACE_D7
IC28.12
(SW6-1 = OFF)
-
CN9.16
-
-
CN3.8
-
-
BSC_D06_TRACE_D6 B7 P21_7
BSC_D06
IC28.47
(SW6-1 = ON)
-
IC22.E6
-
-
IC23.11
-
-
JA3-A.23
-
-
TRACE_D6
IC28.46
(SW6-1 = OFF)
-
CN9.18
-
-
CN3.7
-
-
BSC_D05_GTIOC16B E9 P21_6
BSC_D05
IC28.8
(SW6-1 = ON)
-
IC22.H6
-
-
IC23.10
-
-
JA3-A.22
-
-
GTIOC16B
IC28.9
(SW6-1 = OFF)
- CN2.6 - -
BSC_D04_TRACE_D4 A7 P21_5
BSC_D04
IC28.50
(SW6-1 = ON)
-
IC22.F5
-
-
IC23.8
-
-
JA3-A.21
-
-
TRACE_D4
IC28.49
(SW6-1 = OFF)
-
CN9.22
-
-
CN3.13
-
-
BSC_D03_TRACE_D3 A6 P21_4
BSC_D03
IC28.5
(SW6-1 = ON)
-
IC22.F4
-
-
IC23.7
-
-
JA3-A.20
-
-
TRACE_D3
IC28.6
(SW6-1 = OFF)
-
CN9.24
-
-
CN3.16
-
-
BSC_D02_TRACE_D2 B8 P21_3
BSC_D02
IC28.53
(SW6-1 = ON)
-
IC22.H3
-
-
IC23.5
-
-
JA3-A.19
-
-
TRACE_D2
IC28.52
(SW6-1 = OFF)
-
CN9.26
-
-
CN3.15
-
-
BSC_D01_TRACE_D1 C8 P21_2
BSC_D01
IC28.2
(SW6-1 = ON)
-
IC22.E3
-
-
IC23.4
-
-
JA3-A.18
-
-
TRACE_D1
IC28.3
(SW6-1 = OFF)
-
CN9.28
-
-
CN3.18
-
-
BSC_D00_TRACE_D0 B9 P21_1
BSC_D00
IC28.56
(SW6-1 = ON)
-
IC22.G2
-
-
IC23.2
-
-
JA3-A.17
-
-
TRACE_D0
IC28.55
(SW6-1 = OFF)
-
CN9.38
-
-
CN3.17
-
-
BSC_CS3#_18 N18 P14_5 BSC_CS3#_33 IC13.4 -
IC23.19
-
-
JA3-A.28
-
-
BSC_RAS#_M C1 P00_7 BSC_RAS#
IC12.16
(SW6-1 = ON)
-
IC23.18
-
-
JA3-A.50
-
-
