Renesas Starter Kit+ for RZ/T2M 6. Configuration
R20UT4939EG0100 Rev. 1.00 Page 52 of 87
Apr 20, 2022
Table 6-39 and Table 6-40 below details the function of the jumpers associated with the ETHSW.
Table 6-39: ETHSW Configuration Jumper Settings (1)
CN17
Connect 3.3V Power rail to VCC1833_2. (When using SDRAM)
Connect 1.8V Power rail to VCC1833_2. (When using Ethernet port 2)
Table 6-40: ETHSW Configuration Jumper Settings (2)
When using 3 ports in the same PHY mode
When ports 0 and 1 use the same PHY mode and port 2 uses different PHY modes
*
: When using VCC1833_2 at 3.3 V, use a jumper setting of 2-3.
