Table 6-78, Table 6-79, Table 6-80, Table 6-81, Table 6-82 below details the function of the switches
associated with the mikroBUS™.
Table 6-78: mikroBUS™ Configuration Switch Settings (1)
SW6-1
Explanation
ON
Enable the external bus signal.
OFF
Enables signals other than the external bus. (CAN, Emulator, I
2
C, etc.)
Table 6-79: mikroBUS™ Configuration Switch Settings (2)
SW5-10
SW5-9
SW5-8
Explanation
ON
OFF
OFF
Enable the "M1_UP" signal.
OFF
ON
OFF
Enable the "SCK3" signal.
OFF
OFF
ON
Enable the " MIK_PWM" signal.
Table 6-80: mikroBUS™ Configuration Switch Settings (3)
SW5-7
SW5-6
SW5-5
Explanation
ON
OFF
OFF
Enable the "M1_VP" signal.
OFF
ON
OFF
Enable the "RS485_RXD" signal.
OFF
OFF
ON
Enable the "SCI_RXD" signal.
Table 6-81: mikroBUS™ Configuration Switch Settings (4)
SW6-8
SW6-7
Explanation
ON
OFF
Enable the "MB_RST#" signal.
OFF
ON
Enable the "M1_WN" signal.
Table 6-82: mikroBUS™ BUS Configuration Switch Settings (5)
SW6-6
SW6-5
Explanation
ON
OFF
Enable the "SCI_TXD" signal.
OFF
ON
Enable the "M1_VN" signal.
