Renishaw MP10 - MP10 Dimensions

X-Y overtravel 17.5°
Z overtravel 8 (0.31)
Translational on-centre
adjustment with adjusting plate
Pull stud
(not supplied
by Renishaw)
Typical
taper shank
A
Ø6
(0.24)
22
(0.87)
Probe output
35°
21.5
(0.85)
17.5°
17.5°
Stylus 50
(1.96) long.
Other length
styli may be
used
1-10
MP10 dimensions mm (in)
A
GAUGE LINE
GAUGE LINE
Probe Output
70° OMP shown
with optional
Ø8 mm ball
70°
35° OMP shown
Ø48
(Ø1.89)
Ø62
(Ø2.44)
Ø8 mm ball
See Data sheet taper shanks H-
2000-2011 for dimension A
69.3 (2.73)
71.2 (2.80)
35° OMP 48.8 (1.92)
70° OMP 46.4 (1.82)
Translational on-centre adjustment
(with optional angular adjustment
using centre ball)
67.9 (2.67)
69.8 (2.75)
35° OMP 48.8 (1.92)
70° OMP 46.4 (1.82)
LED
See Data sheet taper shanks H-
2000-2011 for dimension A
