Renishaw MP10 - Performance Envelope

MP10 35° OUTPUT PROBE + OMM
Probe and OMM diodes must be
mutually in each others field of view,
and within the performance envelope
shown.
OPERATING RANGE
The OMP must be within
6 m (19.6 ft) of the OMM.
PERFORMANCE ENVELOPE
1-4
SWITCH-ON/OFF RANGE
The OMP must be within
3 m (9.8 ft) of the OMM.
35° OMP
Optical
centre
line
OMM
60°
45°
60°
45°
15°
30°
30°
15°
0°
SWITCH ON/OFF
OPERATING
Range metres (feet)
2 (6.5)
1 (3.3)
3 (9.8)
4 (13.1)
5 (16.4)
6 (19.6)
45°
90°
15°
60°
15°
75°
45°
30°
30°
2 (6.5)
1
(3.3)
3 (9.8)
4 (13.1)
5 (16.4)
6 (19.6)
