Renishaw MP10 - Page 9

2 (6.5)
1 (3.3)
3 (9.8)
4 (13.1)
5 (16.4)
6 (19.6)
45°
90°
15°
60°
15°
75°
45°
30°
30°
60°
Probe and OMM diodes must be
mutually in each others field of view,
and within the performance
envelope shown.
SWITCH-ON/OFF RANGE
The OMP must be within
3 m (9.8 ft) of the OMM.
OPERATING RANGE
The OMP must be within
6 m (19.6 ft) of the OMM.
MP10 70° OUTPUT PROBE + OMM
PERFORMANCE ENVELOPE
1-5
SWITCH ON/OFF
OPERATING
Range metres (feet)
Optical
centre
line
2 (6.5)
3 (9.8)
4 (13.1)
5 (16.4)
6 (19.6)
OMM
60°
45°
60°
45°
15°
30°
30°
15°
1 (3.3)
70° OMP
0°
