TOOL SETTING
PROBE
Length setting
(rotating and
non rotating)
Diameter setting
(rotating)
Broken tool detection
PROBE COLLISION
PROTECTION
Stylus ball radius
Probe length
CALIBRATION
Internal and external
corner find
Web and pocket measure
Probe XY offset Bore and boss
measure
INSPECTION
Inspection printout
COMPONENT No. 1
OFFSET NO. NOMINAL TOLERANCE DEVIATION FROM COMMENTS
DIMENSION NOMINAL
99 1.5000 .1000 .0105
97 200.0000 .1000 .2054 OUT OF TOL
XYZ single surface
position
SOFTWARE FOR MACHINING CENTRES
Simple to use canned cycles for basic features
1-24
