NO
PROBE READY
FOR USE
see page 1-27
START
The flow chart is provided as a guide
only. Gauge moves are dependant on
the control system.
If there is a system fault alarm, the
operator should check if the probe
status LED is constant red, indicating
battery dead.
OUTPUT ALARM
SYSTEM FAULT
IS
LOW BATTERY
CLEAR ?
READ
LOW BATTERY
SIGNAL
SEND OPTICAL
SIGNAL
WAIT 1 SECOND
READ ERROR
SIGNAL AND
STATUS SIGNAL
NO
YES
YES
NO
NO
YES
ORIENTATE PROBE
TO FIXED
POSITION FOR USE
END
OUTPUT ALARM
SWITCH ON
FAILURE
YES
OUTPUT ALARM
LOW BATTERY
APPROXIMATELY
8 HOURS MAXIMUM
USEABLE LIFE
REMAINS
END
IS ERROR
CLEAR AND STATUS
READY ?
IS ERROR
PRESENT AND STATUS
NOT READY ?
IS ERROR
CLEAR AND STATUS
READY ?
1-26
MP10 - OPTICAL ON
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
CALL
OPERATOR
CALL
OPERATOR
➤
➤
➤
➤
