OMP40-2 installation guide
2.6
OMP40-2 basics
Principal application
Workpiece inspection and job set-up on small to medium machining
centres and small multi-tasking machines.
Dimensions
Length
Diameter
50 mm (1.97 in)
40 mm (1.57 in)
Weight (without shank) With batteries
Without batteries
250 g (8.82 oz)
234 g (8.25 oz)
Transmission type
360° infrared optical transmission (modulated or legacy)
Switch-on methods
Optical on
Switch-off methods
Optical off or Timer off
Spindle speed (maximum)
1000 rev/min
Operating range
Up to 5 m (16.4 ft)
Compatible receiver/
interface
Modulated
OSI with OMM-2 / OMI-2
/ OMI-2T / OMI-2H
Legacy
OMI / OMM with MI 12
Sense directions
±X, ±Y, +Z
Unidirectional repeatability
1.00 µm (40 µin) 2s (see note 1)
Stylus trigger force
(see notes 2 and 3)
XY low force
XY high force
Z
0.50 N, 51 gf (1.80 oz)
0.90 N, 92 gf (3.24 oz)
5.85 N, 597 gf (21.04 oz)
Stylus overtravel
XY plane
+Z plane
±12.5°
6 mm (0.24 in)
Environment
IP rating IPX8 (EN/IEC 60529)
IK rating (OMP40-2 and
OMP40-2 LS)
IK01 (EN/IEC 62262) [for glass window]
IK rating (OMP40M) IK02 (EN/IEC 62262) [for glass window]
Storage temperature
-25 °C to +70 °C (-13 °F to +158 °F)
Operating temperature +5 °C to +55 °C (+41 °F to +131 °F)
Battery types
2 x ½AA 3.6 V lithium-thionyl chloride (LTC)
Battery reserve life
Approximately one week after a low battery warning is first given
(based on 5% usage).
Typical battery life
See page 2.7
Note 1 Performance specification is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 50 mm stylus
Significantly higher velocity is possible depending on application requirements.
Note 2 Trigger force, which is critical in some applications, is the force exerted on the component by the stylus when the
probe triggers The maximum force applied will occur after the trigger point, i.e. overtravel. The force value depends on
related variables, including measuring speed and machine deceleration.
Note 3 These are the factory settings, manual adjustment is not possible.
OMP40-2 specification
