Renishaw OMP40-2 Installation Guide

OMP40-2 installation guide
4.2
Trigger Logic
Factory
settings
New
settings
Switch-on method
Optical switch-on
✔
Switch-off method
Optical off
✔
Short timeout (12 s)
Medium timeout (33 s)
Long timeout (134 s)
Enhanced trigger filter
Off (0 ms)
✔
On (10 ms)
Optical transmission
method
Legacy (start filter off)
Legacy (start filter on)
Modulated PROBE 1
✔
Modulated PROBE 2
Modulated PROBE 3
Optical power
Low
Standard
✔
OMP40-2 serial no ........................................
✔ tick
Probe settings record
This page is provided to note your probe’s settings.
✔ tick
Factory settings are for kit (A-4071-2001) only.
