9Performance envelope with OMI
OMP40 probe + OMI
Probe and OMI diodes must be in the other’s field
of view, and within the performance envelope
shown.
360° range metres (feet)
SWITCH ON/OFF OPERATING
OMP40
OMI
0°
Optical
centre
line
60°
45°
45°
15°
30°
30°
15°
60°
0°
60°
45°
45°
15°
30°
30°
15°
60°
75°
4
(13.1)
3
(9.8)
2
(6.5)
1
(3.3)
5
(16.4)
4
(13.1)
3
(9.8)
2
(6.5)
1
(3.3)
5
(16.4)
