Renishaw OMP40 User Manual

4
A workpiece set-up and inspection probe is, in
effect, another tool in the system. A probe cycle
may be included at any stage of the machining
process.
Signals are transmitted between the probe and
the machine’s control, via the OMI or alternatively
the OMM + MI 12. Interface units convert probe
signals into an acceptable form for the machine’s
control.
Stylus
CNC machining
centre spindle
Typical tool
setting probe
CNC
machine
control
Optional - PSU3
power supply unit
OMP40
inspection probe
Mounting bracket
Interface unit
Cable
Optional - PSU3
power supply unit
Workpiece
OMP - LEDs
(Light emitting diodes)
3 x receive diodes
12 x transmit LEDs
3 x probe status LEDs
OMI
Typical probe system using OMI
Typical probe system using OMI
