32
Changing probe settings
Changing probe settings
Probe settings can be configured using Trigger
Logic.
1. Insert batteries or if already inserted, remove
for 5 seconds and replace.
2. Following the LED check, deflect the stylus
and hold deflected until 5 red flashes occur at
end of the review sequence.
Notes: If battery power is low then each of the
5 red flashes will be followed by a blue flash.
See ‘Probe settings’ for further details.
3. The probe is now in configuration mode and
will flash the current switch off method.
Trigger Logic is now active enabling probe
settings to be changed as shown on next
page.
Note: Settings are saved as they are changed.
KEY
Deflect stylus for less than
4 seconds
Deflect stylus for more
than 4 seconds
Leave stylus untouched
(for period shown)
>20 sec
To Next Page
