Probe length calibration
Typical probe cycles for machining centres
Simple to use canned cycles for basic features
Stylus ball radius
calibration
Inspection probe
collision protection
Internal and external
corner find
Web and pocket
measure
Inspection
Bore and boss measure
XYZ single surface
position
Inspection probe
calibration
Probe XY offset
calibration
Inspection print-out
COMPONENT No. 1
OFFSET NO. NOMINAL TOLERANCE DEVIATION FROM COMMENTS
DIMENSION NOMINAL
99 1.5000 .1000 .0105
97 200.0000 .1000 .2054 OUT OF TOL
