Renishaw OMP40 - Environment and Operating Conditions; Probe Repeatability; Stylus Trigger Force; Probe IP Rating and Weight

13
Environment
Probe repeatability
Maximum 2 Sigma (2
σ) Value;
Repeatability of 1.0 µm (0.00004 in) is valid for
test velocity of 480 mm/min (1.57 ft/min) at stylus
tip, using stylus 50 mm (1.97 in) long
.
Stylus trigger force
X/Y trigger forces vary around the stylus seating.
X/Y direction - typical lowest force 0.50 N / 50 gf
(1.76 ozf)
X/Y direction - typical highest force 0.9 N / 90 gf
(3.17 ozf)
Z direction - 5.85 N / 585 gf (20.62 ozf)
Probe IP rating
IPX8
Probe weight without shank
OMP40 probe
without batteries 242 g (8.53 oz)
OMP40 probe with batteries 262 g (9.24 oz)
OMP40 and system performance
Probe/OMP OMM
MI 12 interface
OMI PSU3
Temperature
Storage
-10 °C to 70 °C
(14 °F to 158 °F)
Normal operating
5 °C to 50 °C
(41 °F to 122 °F)
