Introduction
1 Introduction
This guide describes the installation of the PH10 series of motorised probe heads and the PHC10-2
probe head controller.
The guide gives information on physical installation, system connections, communications and interface
settings, as well as assistance in fault-finding during the installation of a system.
WARNING: The components of the PH10 system are not compatible with PH9 system
components. No attempt should be made to connect PH10 system components to a PH9 system,
as this will result in damage to the product.
The guide should be read in conjunction with the PH10 series user’s guide (Renishaw part number
H-1000-5070) in order to fully understand the system’s features, capabilities and operation.
Associated documentation
Title Part number
PH10 series user’s guide H-1000-5070
HCU1 hand control unit user’s guide H-1000-5016
AM1 adjustment module user’s guide H-1000-4010
AM2 adjustment module - new product information sheet H-1000-2051
Touch-trigger probe user’s guide H-1000-5021
Styli and accessories - technical specifications H-1000-3200
Basic command set for indexing heads programmer’s guide H-1000-5075
PICS installation guide H-1000-5000
Probing systems for co-ordinate measuring machines - H-1000-5050
technical specifications
!
