IEEE parallel communications
5.1 IEEE connector pinouts
The PHC10-2 IEEE488 connector is compatible with any standard IEEE488 cable. The pin numbers and
signals are given in table 5.
Table 5 - IEEE connector pinouts
Pin Signal Pin Signal
1
2
3
4
5
6
7
8
9
10
11
12
D101
D102
D103
D104
EOI(24)
DAV
NRFD
NDAC
IFC
SRQ
ATN
Shield
13
14
15
16
17
18
19
20
21
22
23
24
D105
D106
D107
D108
REN(24)
GND(6)
GND(7)
GND(8)
GND(9)
GND(10)
GND(11)
GND LOGIC
GND(n) refers to the signal ground return of the reference contact.
D101 - D108, EOI and REN return on contact 24.
5.2 IEEE488 capability
The PHC10-2 IEEE incorporates the following capability codes according to the standard IEEE488-1978:
SH1
AH1
T6
TE0
L4
LE0
RL1
PP2
SR1
E1/2
DC1
C0
