Renishaw PH10 User Manual

7
System description
Figure 8 shows the range of extensions, probes and styli which can be used in conjunction with the
PH10M and PH10MQ heads.
Figure 8 - Extensions, probes and styli
* When using a PH10MQ with SP600M a PEM25 extension bar is required to achieve
A = 97.5° or A = 105° in all B-axis positions.
** TP20, TP200 and SP25M are only shown with one module. Other modules are also available, for
further details refer to the necessary users guides H-1000-5008, H-1000-5014 and H-1000-5104
respectively.
Shank
AM1
PH10M
Quill
AM2
PH10MQ
PAA1
PEM1
PEM25
OTP6M
TP6A
TP200**
TP2-5W
SP25M
TP6 TP7M
PEM3
PEM2
PEM1
PEM25
PEL1
PAA3
SP600M*
TP20**
M2 thread styli M3 thread styli M4 thread styli
PEL2
PEL3
PAA2
