XL laser system
XL-80 hardware XL-80 applications
Specifications
Straightness measurement
Axial range
Short range 0.1 to 4.0 m
Long range 1 to 30 m
Straightness measurement range ±2.5 mm
Accuracy
Short range ±0.5% ±0.5 ±0.15M
2
µm
Long range ±2.5% ±5 ±0.015M
2
µm †
Resolution
Short range 0.01 µm
Long range 0.1 µm
Where:
M = measurement distance in metres % = percentage of displayed value
† subject to environmental conditions
Squareness measurement
Range ±3/M mm/m
Accuracy
Short range ±0.5% ±2.5 ±0.8M µm/m
Long range ±2.5% ±2.5 ±0.08M µm/m
Resolution 0.01 µm/m
Where:
M = measurement distance in metres of the longest axis
% = percentage of displayed value

Renishaw XL Series Specifications

General

Laser Wavelength	633 nm
Type	Laser interferometer
Measurement Range	Up to 80 meters
Accuracy	±0.5 ppm
Environmental Compensation	Automatic
Laser Source	HeNe laser
Interface	USB
Power Supply	External power supply unit
