Renishaw XL Series User Manual

26
XL laser system
XL-80 hardware XL-80 applications
Specifications
Flatness measurement
Axial range 0 to 15 m
Flatness measurement range ±1.5 mm
Accuracy ±0.6% ±0.02M
2
µm
Resolution
0.02 µm for 150 mm base
0.01 µm for 50 and 100 mm base
Where:
M = length of the diagonal in metres
% = percentage of calculated flatness
LS350 laser beam steering optic
Steering angle range ±35 mm/m
Axial range 0 to 10 m
Small linear optics kit
Maximum measurement range 4 m
Small retroreflector
Size 15 mm diameter (standard retro-reflector = 38 mm x 37 mm x 30 mm)
Weight <10 g (standard retro-reflector = 100 g)

Renishaw XL Series Specifications

General

Laser Wavelength	633 nm
Type	Laser interferometer
Measurement Range	Up to 80 meters
Accuracy	±0.5 ppm
Environmental Compensation	Automatic
Laser Source	HeNe laser
Interface	USB
Power Supply	External power supply unit
