Cleaning and service
37
8 Cleaning and service
8.1 Adjusting the cutting bars
To ensure that the device will function satisfactorily, it is necessary to check the cutting gap
(target spacing 0.3 mm). The (SL) cutting bars are therefore moveable so that the cutting gap
can be set.
Fig. 28: Access to the cutting bars
• Loosen the four screws in the left cover.
• Loosen the three screws in the right cover.
• Open the grinding chamber door.
• Pull the rotor approx.10 mm out of the grinding chamber until it can move
freely.
U
U
W
W
U
