REXON RL-502 - Annex II; Technical Specifications

PAGE 29
Annex II
GENERAL
Frequency 136-174MHZ
400-470MHz
Channel Numbers 128
Channel Spacing 12.5KHz/25kHz
Modulation Mode. F3E (FM)
Supply Voltage 7.4V DC
Operation Temperature- 25°C to +60°C
Frequency Stability ± 2.5ppm
Size (mm) W 59 x L 122 X H 40
Weight 220 grams w/o battery back
Approval Directive EN 301 783
TRANSMITTER
RF Output Power VHF 5W/1W; UHF 4W/1W
Max.Freq. Deviation 5KHz
Adjacent Channel Power 60dB
Audio Distortion 5%
RECEIVER
Selectivity 0.18uV @12dB SINAD
Adjacent Channel Selectivity 60dB
Spurious Response Rejection 60dB
Intermodulation 60dB
Audio distortion 5%
Technical Specifications
