REXROTH CS351 User Manual

64 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
Device description
Fig. 1: Compact System view
Legend relating to Fig. 1:
1 Name plate
2 Front cover lock
3 Cable duct strip
4 Side cable ducts
5 Affixed pressure compensation membrane
(do not remove)
6 Safety warning (only visible when the front
cover is open)
7 Type label
Safety warning
It warns against the high electrical voltages in
the Compact System during operation and
provides maintenance information (see “Dis-
assembly and replacement” on page 101).
3
4
4
2
1
5
6
7
CS351_zweispaltig - D.book Seite 64 Dienstag, 16. Juli 2013 12:00 12
