3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 103 /108
Technical data
ENGLISH
15 Technical data
Table 21:
General data
Designation CS351E-D CS351E-G CS351S-D CS351S-G CS351E-D
NK
CS351S-D
NK
IL designation CS351E-D IL CS351E-G IL CS351S-D IL CS351S-G IL – –
CC designation CC-CS351E-
D
–––––
IL designation
with computer
card
– CS351E-G+ – CS351S-G+ – –
Order number 0 608 830
257
0 608 830
258
0 608 830
254
0 608 830
255
0 608 830
281
0 608 830
282
IL order number 0 608 830
274
0 608 830
275
0 608 830
276
0 608 830
277
––
CC order number 0 608 830
289
–––––
IL order number
with computer
card
– 0 608 830
293
– 0 608 830
294
––
Dimensions
(width x height x
depth)
210 x 357.6 x 245.5
Weight 9.7 kg 9.9 kg 9.7 kg 9.9 kg 9.9 kg 9.9 kg
Storage tempera-
ture range
–20 °C ... + 70 °C
Protection type
according to EN
60529/IEC529
IP 54
Installation posi-
tion
Vertical
Voltage 1x 230 V (±10%) 50 - 60 Hz or
1x 120 V (+5% - –10%) 50 - 60 Hz
a)
or
1x 110 V (±10%) 50 - 60 Hz
a)
(automatic voltage selector switch integrated)
Rated current 10 A (at 120 V)/ 5.2 A (at 230 V)
Peak power 4800 VA
Nominal power 1200 VA
c)
a)
The power of size BG5 spindles is limited for supply voltages between 110–120 V (50–60 Hz).
Here, the maximum torque which can be achieved is 70 % of the spindle nominal torque.
b)
23 W with activated screensaver
c)
Use a slow-blow fuse for high starting currents.
