Assembly
ENGLISH
6 Assembly
Assembling the Compact System
Always observe the ambient conditions spec-
ified in the technical data (see “Technical
data” on page 103).
On delivery, the Compact System has two
preassembled metal brackets on the rear
(wall bracket and a lift-out protection). The
Compact System is hung in the suspension
strip (in the scope of delivery) mounted to the
wall using the wall brackets. The Compact
System must be bolted down at the lift-out
protection to ensure that it is not unintention-
ally taken off the suspension strip.
CAUTION
Risk of damage to persons and prop-
erty!
Assembly of the Compact System re-
quires basic mechanical and electrical
knowledge.
No other persons than qualified per-
sonnel (see “Personnel qualification”
on page 59) are authorized to assem-
ble the Compact System.
WARNING
Dangerous shock currents due to in-
sufficient PE wire connections!
Danger to life
Make sure that the PE wire connec-
tions have not been damaged by me-
chanical, chemical or electrochemi-
cal influences. A permanent
connection is required.
CAUTION
Destruction of electrical compo-
nents!
Health risk
Do not destroy any installed compo-
nents. Properly dispose of destroyed
components.
CAUTION
Electrostatic discharge!
Damages to the compact system
Comply with all the precautions for
ESD protection when handling com-
ponents and modules! Avoid electro-
static discharge!
