Bosch Rexroth AG CS351/CC-CS351

| 3 609 929 B45/2013-06

Assembly

Fig. 26: Wall bracket (dimensions in mm)

1 Wall bracket

2 Lift-out protection

295

6.4

ø 6.4

4.5

2.5

160

210

358

295

210

252,5
