2020 rf IDEAS Inc rfIDEAS Configuration Utility User Manual P a g e  32
B Enable the extend mode on that configuration Click on Write to save
extend mode in the reader
C Open the Get ID and present the cardThe GetID box will close automatically
in few seconds
D Start making changes in extended settings afterward and click on Write in
the end to save those
GetID  Press the button and present the new card to the reader this must happen each
time a new card is used The information is used to set the max number of bits on the card
and the bits displayed in bit window of the utility
Define Fields It is only available for the FIPS 201 RDR7P71AKU and OEM chuid board reader
types Pressing this button will let the user select from the list of predefined card formats
Start Bit Enter a number to define the left most significant starting bit for the field
Number of Bits Enter the number of bits used for the field data This value is added to the
Start Bit to define the range of bits used in the field
Insert Keystroke Enter the delimiters in the delimiter text box USB readers Delimiters for
serial readers are entered using the virtual keyboards
Clear Pressing the clear button will clear the delimiters in the delimiter text box
Decimal Enables the reader to output the card field in decimal format
Hex Enables the reader to output the card field as a base 16 number in uppercase hex
ASCII Displays Card Data in ASCII Character Mode where every byte represents a printable
ASCII Character The ASCII data bit field shall be in multiples of 8 bits and each field bit
pattern must define a printable ASCII character 0x20 thru 0x7F otherwise warnings 
will be displayed in the lower left portion of the Where box on the rf IDEAS Configuration
Utility Extended TAB screen
NOTE:
¾ ASCII Extended Mode is available only for Secure Type Readers that are compatible
with MIFARE DESFire EV1EV2 Cards LEAF Smart Cards and similar technologies For
readers supporting ASCII Character Mode contact Salesrfideascom See ASCII
Extended Procedure in the Appendix to configure reader for ASCII Extended Mode
Configuration
¾ Before the reader can be configured in the ASCII Display mode the reader must be
preconfigured in advance using the Smartcard Manager Utility Contact
techsupportrfideascom for more information
