User manual RF-KIT Power Amplifier RF2K-S
3. Control elements and connections
3.1 Panel description
1 On/O
2 Touch screen
3 ANT 4
4 ANT 3
5 ANT 2
6 ANT 1
7 PTT
8 Power On External
9 Power jack
10 Fuse
11 Ground connector
12 Multifunction connector
13 LAN
14 Cooling fan
15 CAT USB
(USB-port is provided by the Raspberry Pi®)
16 -55 dB output
17 Exciter input
0
I
Front panel:
Rear panel:
1
2
5
6
4
3
14
12
16
15
13
7
8
9
11
10
17
