RGBlink M1 User Manual

M1 User Manual
18
Input
Input 1 Input 2 Input 3 Input 4
Input 1
Input Port 1
Brightness 100
Contrast 50
Saturation 50
Sharpness 100
Temperature RED 128
Temperature GREEN 50
Temperature BLUE 50
Reset Config >>
3.3.1 Input Menu
Push [MENU] button, and enter the menu items. Turn the rotary knob, select [Input Menu]
option in LCD screen, push the knob or touch the icon directly to confirm, and enter the
menu as follows:
Select any input and enter the menu:
Input Port
Users can select 0 or 1.
Brightness
The adjustment range is from 0 to 100.
Contrast
The adjustment range is from 0 to 100.
Saturation
The adjustment range is from 0 to 100.
Sharpness
The adjustment range is from 0 to 100.
Temperature RED
The adjustment range is from 0 to 128.
Temperature GREEN
The adjustment range is from 0 to 128.
Temperature BLUE
The adjustment range is from 0 to 128.
Reset Config
Reset input parameter.
3.3.2 Output Menu
Push [MENU] button, and enter the menu items. Turn the rotary knob, select [Output Menu]
