3.5 PGM Mode
1. Switch the edited PST image to program by pushing the [CUT], [TAKE] button or T-bar, and then
the PGM image will return to PST state, which can be edited.
2. There are 1 HDMI output and 1SDI output for program, and up to support 1920x1080 output
resolution.
3.6 Switching Mode
1. T-BAR switch: Switch the PST image to program with wipe and fade by T-bar.
2. CUT switch: Seamless switch the PST image to program by pushing [CUT] button.
3. TAKE switch: Switch the PST image to program with wipe and fade by pushing [TAKE] button.
4. CUE switch: EARPHONE voice via CUE transfer PST to PGM.
5. MUTE switch: MUTE only for PGM voice.
