M1 User Manual

Standard C_1024×768@60

Custom Format On

HActive 1024

VActive 768

Freq 60

Set >>

3.7 Set the Output Parameter

Select the Output Resolution

Push the [MENU] button, and enter the menu items, turn the rotary knob and select <Output> or

Push the rotary knob to confirm, and enter to the menus as below:

<Output Format> is the default option, push the rotary to confirm. Turn the rotary knob, select

the output resolution according to actual need.

Customs Output Resolution

Continue the above operation, setting the HActive, VActive, Freq, and select <Set>, confirm the

Set setting to Yes.Then the LCD screen shown as below:

Output Setting

Push the rotary knob or touch the button <Output setting> to confirm, and enter the menus as

below:

DVI or HDMI output format can be chosen for PST and PGM output port, SDI Level choose Level A

or Level B.

External Sync

External Including option Off and On, Input will shown as actual input resolution.

Output Format

Output Setting

External Sync

Test Pattern

PST DVI

PGM DVI

SDI Level Level A
