LOAD FROM
->PAGE: 1
BANK: 1
LOAD FROM
->PAGE: 2
BANK: 1
LOAD FROM
PAGE: 2
->BANK: 2
3.10 Recall Saved Settings
M1 provides 20 positions for saving or recording parameters. To recall saved settings:
(1) Push the [LOAD] button in Presets operation area, the button [LOAD] and [PAGE] lights are lit,
and some of buttons 1~5 are lit and some are flashing. The button lit is ready for recall and
flash means just recall, push the button lit to recall.
(2) Select PAGE, for example, the button [2] is lit, push the button [2].
(3) After set the PAGE, it will jump to BANK option, or example, the button [2] is lit, push the
(4) Push the [LOAD] button again, the button light is off, and exit the load function.
