3.3.15 System
Push [MENU] button, and enter the menu items. Turn the rotary knob, select [System] option in
LCD screen, push the knob or touch the icon directly to confirm, and enter the menu as
follows:
English
Select [English] and push the knob to confirm or touch [English] to choose English.
中文
Select [中文] and push the knob to confirm or touch [中文] to choose Chinese.
Transition
Trans Time
The adjustment range is from 1.0S to 9.9S.
Version
Show the version of COM MCU, EXT MB MCU, PGM MCU, PGM
Core, KEY MCU.
Ethernet
DHCP
Enable or disable the network function. If select [ON], user can set
the IP address, subnet mask and gateway.
State
Show the present state of DHCP, IP, Subnet Mask, Gateway.
T-Bar Correction
Step 1: Press the T-BAR to the top
Step 2: Choose On or Off
Step 3: Press the T-BAR to the bottom
Step 4: Choose On or Off
T-Bar Calibration: 1024
Fader Correction
Step 1: Push Fader 1&2 to top
Step 2: Choose On or Off
Step 3:Push Fader 1&2 to the bottom
Step 4: Choose On or Off
Fader Calibration: 0:0
Key Board
MASK
Users can custom Self, Black or FS.
PGM LOGO
Users can custom Self or PGM Freeze.
PST LOGO
