RGBlink M1 User Manual

M1 User Manual
20
External Sync
External On
Input No Input
Format 1280×720@59.94
Test Pattern
Output PST
Test Pattern Off
Red 0
Green 0
Blue 0
Turn the knob or touch [External Sync] to enter the menu as follows:
Turn the knob or touch [Test Pattern] to enter the menu as follows:
Output Format
Standard
Users can select standard resolution as actual.
Output Setting
Output Port
Select PST OR PGM.
DVI/HDMI
Select DVI or HDMI.
Bit Depth
When select DVI, the default bit depth is 8 Bits; when select
HDMI, the bit depth can be 8 Bits or 10 Bits.
Color Space
Select Image or Video.
DE ADJUST
Select On or Off to enable or disable DE adjust.
Set the horizontal position of output signal.
Set the vertical position of output signal.
Set the horizontal size of output signal.
