Subsystems
CGS-240 Manual 6/15/2021
Page 73 of 148
6.6.2 AC CONTROL
The ECB’s AC CONTROL section (A0-A7) are digital outputs at a 5-volt logic level. They are primarily used as the
control signals for high power AC relays. LEDs adjacent to each output indicate the status. When an LED is on, it
indicates the digital output is active and it’s (-) pin is being pulled to a logic low. The (+) pin of each digital output is
hard wired to +5 VDC.
6.6.3 A/D INPUTS
The ECB’s A/D INPUTS section (AD0-AD7) has an 8 channel, 14-bit, 5-volt analog to digital converter system. Each
connector also has 12 VDC power available to directly power the connected devices or sensors.
Analog Input
Description
Reference
AD0
P
RH,
Refrigeration High-side Pressure Sensor
Section 6.4.6
AD1
P
RL
, Refrigeration Low-side Pressure Sensor
Section 6.4.6
AD2
L
LT
, Tube Liquid Presence
Section 6.3.3
AD3
Temp Board power
Section 6.1.3
AD4-AD7
N/A
6.6.4 LEVEL INPUTS
Digital
Output
Description
Reference
A0
Comp 1, Compressor
Section 6.4.1
A1
H1, Presat Heater
Section 6.1.4.2
A2
H2, Sat Heater
Section 6.1.4.3
A3
H3, Chamber Heater
Section 6.1.4.4
A4
FAN 2, Chamber Fan
Section 6.5.2
A5
H5, Window Pane Heater
Section 6.1.5.1
A6
H6, Window Frame Heater
Section 6.1.5.2
A7
N/A
