Rhymebus RM6F5 series User Manual

Chapter 5 Parameter Setting Description
105
5
Func.
Name
Description
F_125
Selection of
Frequency
Command by
Manaul Mode
under Close-
Loop
Condition
=0: Analog input terminal (Vin)
=1: Keypad “ ” or “ ” key setting
=2: Keypad setting knob
=3: RS-485 Communication interface
*In close-loop control, select the speed command source when
feedback signal is bypassed in temporary.
*When the multi-function input terminal is set to
+
13 (Under
close-loop control condition (F_103≠0), open-loop selection.)
F_126
Iin Range
Selection
=0: 4~20mA (2~10V).
=1: 0~20mA (0~10V).
*According to the specification of pressure transmitter to select the Iin
range.
F_127
Iin Gain
(Analog
Input)
․The gain ratio of analog input terminal Iin.
*Set the gain ratio for the feedback signal from pressure transmitter.
F_128
Iin Bias
(Analog
Input)
․The bias ratio of analog input terminal Iin.
*Set the bias ratio for the feedback signal from pressure transmitter.
