Chapter 1 Cautions Before Installation
1-1 Product Verification
The product has passed the strictest quality test before shipped out from the
factory. However, the product might possibly sustain minor damages due to the
impact, shaking, vibration, and other factors during the transportation. Please
make sure to verify the following items after receiving this product. If the product
verification finds anything abnormal, please contact the agent immediately for the
further assistance.
1-1-1 Confirmation of Appearance
1. Check up the specifications at shipping label on the carton is identical
with the nameplate of drive.
2. Check up the appearance of drive for any paint chipped off, smearing,
deformation of shape, etc.
3. Check up the nameplate (as below example by RM6F5-2001) of the
drive to verify the product descriptions with the order specification.
Rhymebus Corporation, TAIWAN
BXXXXXXXX
0041-d(AZXXXXXX)
3PH 200-240V 0.1-120Hz 4.2A
3PH 200-240V 5A 50/60Hz
RM6F5-2001B3
SERIAL NO.
PGM NO.
OUTPUT
INPUT
TYPE
Model Number
Input Power Specs
Output Current & Capacity
Software Number
Product Serial Number
ISO 9001 IP20
BXXXXXXXX
1-1-2 The description of nomenclature:
RM6F5 – 2 001
Model code
Input voltage
2：AC 200~240V
4：AC 380~480V
Product series
Please refer to maximum
applicable motor
Maximum applicable motor
Model
code
HP/kW
Model
code
HP/kW
Model
code
HP/kW
Model
code
HP/kW
001
1
0.75
020
20
15
100
100
75
350
350
250
002
2
1.5
025
25
18.5
125
125
90
420
420
315
003
3
2.2
030
30
22
150
150
110
500
500
375
005
5
3.7
040
40
30
175
175
132
600
600
450
007
7.5
5.5
050
50
37
200
200
160
700
700
500
010
10
7.5
060
60
45
250
250
200
－
－
－
015
15
11
075
75
55
300
300
220
－
－
－
