Chapter 6 Parameter Description of Pump
106
5
․ 6-1-2 Manual Mode
1. When the multi-function input terminal is set to +13 (Under close-loop control condition
(F_103≠0), open-loop selection.)
2. Press
HAND
ON
key to control.
Example:
․Automatic Mode Manual Mode, press
HAND
ON
key (HAND ON LED light)
․Manual Mode Automatic Mode, press
HAND
ON
key (HAND ON LED light)
*The drive will resume to the previous frequency setting when the manual mode turns off.
Func.
Name
Description
F_125
Selection of
Frequency
Command by
Manaul Mode
under Close-
Loop
Condition
=0: Analog input terminal (Vin)
=1: Keypad “ ” or “ ” key setting
=2: Keypad setting knob
=3: RS-485 Communication interface
*In close-loop control, select the speed command source when
feedback signal is bypassed in temporary.
F_162
Frequency
Upper
Limitation by
Manual Mode
* Setting Frequency Upper Limitation:
The drive only follow F_162 setting value.
* Upper Limitation(Manual Mode) =
Maximum output frequency (F_017)*F_162
* Setting range: 0~100%(default value:100)
F_163
Frequency
Lower
Limitation by
Manual Mode
* Setting Frequency Lower Limitation:
The drive only follow F_163 setting value.
* Upper Limitation(Manual Mode) =
Maximum output frequency (F_017)*F_163
* Setting range: 0~100%(default value:100)
