Rhymebus RM6F5 series User Manual

Chapter 2 Installation and Confirmation
12
2
1-1-3 Confirmation of Accessories
One operation manual is inclusive. Please verify other accessories
inclusively such as braking resistor, AC reactor, etc..
※Please refer to the standard specifications to verify the product
specifications with your requirements.
1-2 Standard Specifications
1-2-1 Three-Phase 200V Series
Model name
(RM6F5-□□□□)
2001
2002
2003
2005
2007
2010
2015
Maximum applicable
motor (HP / kW)
1/0.75
2/1.5
3/2.2
5/3.7
7.5/5.5
10/7.5
15/11
Rated output capability
(kVA)
1.6
2.6
3.8
5.8
9.5
12
16
Rated output current (A)
4.2
6.8
10
15.2
25
31
42
Rated output voltage (V)
Three-phase 200~240V
Range of output
frequency (Hz)
0.1~120.00Hz
Power source (ψ, V, Hz)
Three-phase 200~240V 50/60Hz
Input current (A)
5
8
12
18
30
41
55
Permissible AC power
source fluctuation
176~264V 50/60Hz / ±5％
Overload protection
120% of drive rated output current for 1 min.
Cooling method
Nature
cooling
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
1.8
1.8
1.9
2
5.3
5.3
5.4
