Appendix B Selection of AC Reactor(ACL)
152
App.C
AC Reactor (ACL) Specifications
Drive model
number
Input
(R/L1,S/L2,
T/L3)
Output
(U/T1,V/T2,
W/T3)
Drive model number
Input
(R/L1,S/L2,
T/L3)
Output
(U/T1,V/T2,
W/T3)
(mH)
(A)
(mH)
(A)
(mH)
(A)
(mH)
(A)
RM6F5-2001
1.0
15
1.0
15
RM6F5-4001
1.0
15
0.45
15
RM6F5-2002
1.0
15
1.0
15
RM6F5-4002
1.0
15
0.45
15
RM6F5-2003
1.0
15
1.0
15
RM6F5-4003
1.0
15
0.45
15
RM6F5-2005
1.0
15
1.0
15
RM6F5-4005
1.0
15
0.45
15
RM6F5-2007
0.2
30
0.2
30
RM6F5-4007
1.0
15
0.45
15
RM6F5-2010
0.2
30
0.13
50
RM6F5-4010
0.2
30
0.2
30
RM6F5-2015
0.13
50
0.13
50
RM6F5-4015
0.2
30
0.2
30
RM6F5-2020
0.13
50
0.07
75
RM6F5-4020
0.2
30
0 .13
50
RM6F5-2025
0.07
75
0.05
100
RM6F5-4025
0.13
50
0.13
50
RM6F5-2030
0.05
100
0.05
100
RM6F5-4030
0.13
50
0.13
50
RM6F5-2040
0.05
100
0.035
150
RM6F5-4040
0.13
50
0.07
75
RM6F5-2050
0.035
150
0.025
200
RM6F5-4050
0.07
75
0.05
100
RM6F5-2060
0.025
200
0.025
200
RM6F5-4060
0.05
100
0.05
100
RM6F5-2075
0.025
200
0.015
300
RM6F5-4075
0.05
100
0.035
150
RM6F5-2100
0.015
300
0.013
400
RM6F5-4100
0.035
150
0.025
200
RM6F5-2125
0.013
400
0.013
400
RM6F5-4125
0.025
200
0.025
200
RM6F5-2150
0.013
400
0.01
600
RM6F5-4150
0.025
200
0.015
300
RM6F5-2200
0.006
800
0.006
800
RM6F5-4175
0.015
300
0.015
300
RM6F5-2250
0.006
800
0.005
1000
RM6F5-4200
0.015
300
0.013
400
-
-
-
-
-
RM6F5-4250
0.013
400
0.013
400
-
-
-
-
-
RM6F5-4300
0.013
400
0.01
600
-
-
-
-
-
RM6F5-4350
0.01
600
0.01
600
-
-
-
-
-
RM6F5-4420
0.01
600
0.006
800
-
-
-
-
-
RM6F5-4500
0.006
800
0.005
1000
-
-
-
-
-
RM6F5-4600
0.006
800
0.005
1000
RM6F5-4700
0.005
1000
0.005
1000
