Rhymebus RM6F5 series User Manual

Chapter 2 Installation and Confirmation
17
2
Operation Characteristics
Operation method
(FWD)/(REV) rotation control, 9 sets preset speed control, 3
wire start/stop FWD&REV rotation control, Communication
control
Input
Multi-function
inputs
4 sets programmable input terminals: X1~X4
Refer to the function setting description of F_052~F_055
Analog
inputs
․Vin – GND: DC 0~10V
․Iin – GND: DC 4~20mA / 2~10V or DC 0~20mA / 0~10V
Refer to the function setting description of F_040, F_041, and
F_126~F_128
Output
Multi-function
outputs
4 sets programmable output detection: Ta2–Tc2, Ta1–Tb1–
Tc1, Y1–CME, Y2–CME
Refer to the function setting description of F_058~F_061
Analog
outputs
․―FM+‖ – ―M-―：DC 0~10V
․―AM+‖ – ―M-―：DC 0~10V
Refer to the function setting description of F_044, F_045,
F_129, F_130
Display
Keypad (KP-605)
output frequency, frequency command, output voltage, DC
bus voltage, output current, terminal status and heat sink
temperature, actual / setting pressure.
External indicator
(DM-501)
Independent external display can be added for up to three
sets(96mm * 48mm, 5 digits) to show output frequency,
frequency command, output voltage, DC bus voltage, output
current, terminal status and heat sink temperature.
Protections
Fault protection
Error trip
messages of
drive
EEPROM error(EEr), A/D converter error(AdEr), Fuse
open(SC), Under voltage during operation(LE1), Drive over
current(OC), Grounding fault (GF), Over voltage(OE), Drive
overheating(OH), Motor overload(OL), Drive overload(OL1),
System overload(OLO), External fault(thr), NTC thermistor
sensor fault(ntCF), Keypad interruption during copy(PAdF)
Error trip
messages of
drive for
pressure
control
PID feedback signal error(no Fb), Over pressure(OP), Water
shortage(Fb Lo)
Warning
messages of
drive
Power source under voltage(LE), Drive output interruption
(bb), Coast to stop(Fr), Dynamic brake transistor over
voltage(db), Software fault(PrEr), Drive overheating(Ht),
Keypad cable trip before connecting(Err_00), Keypad cable
trip during operation(Err_01), Over pressure(OP), FWD/REV
command input simultaneously(dtF)、Different software
version inter-copy(wrF)
