Some of the stepper motor drivers directly mark the pulse number of the
revolving one full turn.
Distance of machine moved when motor revolving one full turn calculation formula:
a.
Lead screw drive machine=lead screw pitch*transmission ratio
b.
Rack (straight tooth) drive machine=rack module*gear teeth*pi*transmission ratio
c.
Rack (helical tooth) d
ratio/cos(helix angle)
d.
Belt pulley and belt drive machine=pi*belt pulley diameter*transmission ration
So, stepping motor system calculation formula:
 Lead screw drive:
Name
plate 1 for stepping drive Nam
Instruction：
The Pulse/rev in Nameplate 1 represents the pulse number of motor
revolving one full turn. At this moment, we need only choose the corresponding value
according to the actual dial without computing the numerator in the calculation formula.
For example, if
you choose 3200 in Nameplate 1, then we could get that
angle)*
subdividing number of drive=3200.The MSTEP in Nameplate 2 represents the
