(4) Processing file error.
Check processing file, try to download the correct processing file
to U disk or handle internal.
(5)
There is something wrong with the lines
Replace the lines.
4. Return to the
machine
body
Analysis and solutions：
Three press
the "menu" button
check
whether the detection signal is normal
(1) The
origin detection switch is damaged.
(2)
The distance of the origin detection switch detection sheet beyond the detection range
of the switch, adjust the position of the test piece.
(3)
The origin detection switch to the interface board
check the connections.
(4) The interface board is
broken.
(5) 50-
pin data cable is broken.
5
. Back to the machine origin
Analysis and solutions：
(1)
The origin detection switch types do not match with the definition of the corresponding
level.
Modify the level.(Normally open type corresponds to a level defined the direction of
the arrow down, normally closed type corresponds to the
(2)
The origin detection switch is damaged.
(3)
The origin detection switch connects interface board not well.Refresh the line to
determine
the wiring is correct.
(4)
Too much interference, resulting in the illusion of the detection switch has been
triggered. Recalibrate
the whole circuit.
(5)
The interface board is broken.
(6) 50-
pin data cable is broken.
6
. Abnormally working when
from the processing file
Analysis and solutions：
(1) The program disorder.
(2)
External interference is too
weak current, "GND" of inverter separat
