10 August, 2001 SERVICE PROGRAM MODE
4-67
Service
Tables
Downloading NVRAM Data (SP5-825)
This downloads data from a flash card to the NVRAM inside the machine.
The following data are not downloaded from the flash card:
• Total count categories (SP7-003-*** Copy Counter)
• C/O, P/O Counter (SP7-006-*** C/O, P/O Count Display)
• Duplex, A3/DLT/Over 420 mm, Staple and Scanner application scanning
counters (system settings).
1. Turn off the main switch.
2. Remove the application cover [A].
3. Plug the flash memory card [B] into the card slot.
4. Turn on the main switch.
8. Open SP5-825.
5. Touch “Execute” to start download the NVRAM data.
6. Turn off the main switch, then remove the IC card.
Note that the following errors could occur during downloading:
• If a card is not installed in the card slot and a message tells you that
downloading cannot proceed, you cannot execute downloading, even by
pressing “Execute”
• If the correct card for the NVRAM data is not inserted in the card slot, after you
press “Execute” a message will tell you that downloading cannot proceed
because the card is abnormal and the execution will halt.
B022S999.WMF
[A]
[B]
