Ricoh Aficio BP20 - Windows NT V4.0 (TCP;IP)

Page 2-8 Administratior Guide
Print Driver Installation for Networked Printers
Windows NT V4.0 (TCP/IP)
NOTE: Microsoft TCP/IP Printing must be installed and running on the workstation.
Use the Add Printer Wizard to add the printer to the network.
¾ At the Windows NT workstation, select [Start], select [Settings], and then select [Control
Panel].
Double-click on the [Network] icon and then select [Services].
Ensure that Microsoft TCP/IP Print Service is running and select [Start], select [Settings],
and then select [Printers].
Double-click on the [Add Printer] icon to display the Add Printer Wizard.
¾ Select [My Computer] and then select [Next] to display the dialog box listing available
ports.
Select [Add Port] to display the Printer Ports dialog box.
Select [LPR Port] and select [New Port] to display the Add LPR compatible printer dialog
box.
¾ Enter the IP Address of the printer in the [Name or address of server providing lpd]
field.
Enter [lp] (in lower case) in the [Name of printer or print queue on that server] field.
NOTE: lp must be entered regardless of the name of the printer or print queue. lp is
the name of the remote printer/server on the printer. This name does not change.
Select [OK].
Select [Close].
¾ With the New Port selected, select [Next].
Insert the CD ROM with the printer drivers into the workstation and select [Have Disk].
Browse to the required Windows NT driver on the CD ROM and select [OK].
NOTE: The driver will be found in the Printer folder on the CD in the appropriate
PCL folder. The driver is identified by the file extension .inf.
