Ricoh Aficio BP20 - Snmp

Administratior Guide Page 3-9
Network Installation Using Internet Services
SNMP
Use these instructions to configure the Simple Network Management Protocol (SNMP) using
Aficio BP20N.
Configure SNMP
To configure SNMP, perform these steps:
¾ Enable Aficio BP20N (see “Enabling Internet Services” on page 3-5).
¾ At the Aficio BP20N Home Page for the Aficio BP20N, select the [Network
Administrator] tab.
¾ Click SNMP menu in the left frame
¾ Check if the SNMP Configuration Traps details are correct. If any of the details are
incorrect then enter the correct information.
¾ Click the [Apply] button to implement any changes.
¾ Click Community Names link under the top menu.
¾ Check if the SNMP Configuration Community Names details are correct. If any of the
details are incorrect then enter the correct information.
¾ Click the [Apply] button to implement any changes.
NOTE: Click the [Reset] button to cancel any changes made and return to the
previous values.
