Hard Disk (D362, only for D017/D019)
D017/D018/D019/D020 1-72 SM
1.19 HARD DISK (D362, ONLY FOR D017/D019)
1.19.1 ACCESSORY CHECK
No. Description Q’ty For D017/D019
1 HDD Unit 1
2 Screw 3
3 Keytop: Copy 2
4 Keytop: Document Server 2
5 Knob Screw 3 ---
= Necessary, --- = Not necessary
1.19.2 INSTALLATION
1. Remove the plastic application cover ( x1).
2. Remove the controller board. (See ‘Controller Board’.)
3. Attach the HDD unit [A] to the controller board bracket ( x2, x3).
4. Reinstall the controller board with the HDD.
After Installing the HDD
1. Do SP5832-001 to format the hard disk.
2. Do SP5853-001 to copy the preset stamp data from the firmware to the hard disk.
3. Do SP5846-040 to copy the address book to the hard disk from the controller board.
4. Do SP5846-041 to let the user get access to the address book.
5. Turn the main power switch off/on.
