Copier Installation
D017/D018/D019/D020 1-14 SM
3. If the HDD will be installed for a –17, -29 model, attach the HDD caution decal [B] to
the front cover.
SP Settings
1. Connect the copier and turn the machine on.
2. Go into the SP mode and do SP2801 (Developer Initialization).
3. Do SP1912 and SP1913 to set automatic paper size selection for the upper and lower
tray.
1912
1: Tray: Auto Paper Size Detection Upper Tray
1913
2: Tray: Auto Paper Size Detection Lower Tray
1 Size 1: B5/Exe Landscape
2 Size 2: A5/HLT
3 A4/LT
4 A4/LG
5 A3/LT
[0 to 1/0/1]
0: ISO (A3, A4, A5, etc.)
1: USA (DLT, LT, EXE, etc.)
4. Enable the NIB and/or USB function.
 To enable the NIB function, enter the SP mode and set SP5985-001 (On Board
NIC) to "1"(Enable).
 To enable the USB function, enter the SP mode and set SP5985-002 (On Board
USB) to “1"(Enable).
