Dip Switches
SM 25 D366
ARDF DF3030
D366
3. SERVICE TABLES
3.1 DIP SWITCHES
DIP-SW
1 2 3 4
Function
0 0 0 0 Normal operating mode (Default)
0 0 0 1 Free run: With original: One-sided mode: 100% speed
0 0 1 0 Free run: With original: Two-sided mode: 100% speed
0 0 1 1 Free run: No original: One-sided mode: 100% speed
0 1 0 0 Free run: No original: Two-sided mode: 100% speed
0 1 0 1 Free run: With original: One-sided mode: 32% speed
0 1 1 0 Free run: With original: Two-sided mode: 32% speed
0 1 1 1 Free run: With original: One-sided mode: 70% speed
1 0 0 0 Free run: With original: Two-sided mode: 70% speed
1 0 0 1 Free run: With original: One-sided mode: 200% speed
1 0 1 0 Free run: With original: Two-sided mode: 200% speed
1 0 1 1 Transport Motor On
1 1 0 0 Feed Motor On
1 1 0 1 Transport Motor On with random mode
1 1 1 0 Feed Motor On with random mode
1 1 1 1
